SPECIFICATIONS
| Model |
NPIC6 |
NPIC9/10 |
NPIC12 |
| Extinguisher capacity |
6kg |
9/10kg |
12kg |
| Fire rating |
21A 113B C |
27A 144B C |
43A 183B C |
| Working pressure |
14bar |
| Test pressure |
30bar |
| Total weight |
11kg |
14.5/15.5kg |
18.5kg |
| Range of discharge |
6-8m |
6-8m |
6-8m |
| Duration of discharge |
14-16 sec |
16-18 sec |
18-22 sec |
| Operating temperature |
-20°c to +60°c |
Features :
- Rugged, durable, reliable fire protection.
- Highly effective on class A, B, C & electrical fires.
- Incorporated with high pressure internal co2 cartridge.
- Easy maintenance.
- Field rechargeable.
- Simple and safe operation.
- Safety valve is provided on the main valve to ensure safety.
- Ideal for use in corrosive and harsh service conditions such as offshore platforms and marine jetties.
- Electrostatic powder painting after shot blasting ensures maximum corrosion resistance.
Options :
- Special NPICS-CD(X) series with metal dry powder for CLASS D fire of magnesium, sodium etc.
- Special NPICS(X) series with sodium bicarbonate for CLASS B & C fires
- Special NPICS-M(X) Series with monnex powder for Class B & C fires
- Special NPICK-(X) Series with stop fire K for Class B & C fires
- Special pvc internal coating
- Plastic base
Applications :
Internal cartridge extinguishers are designed for the protection of
ordinary and high risk hazards. It can be used for reliable fire
protection in many industries and applications including refining,
petro-chemical, oil and natural gas production, mining, transportation,
utilities, metal processing, paint process areas, welding areas,
material storage areas and many others.
|
