Features

• LED for 360’ vision
• Combined all the features of the D-C401C Optical and the D-C402C Heat detector
• Sensing chamber for exceptional dust proof ability
• Ideal alternative to Ionization detector
• Low profile design

Technical Specifications

1. Standard: EN54-part 5, part 6 and part 7
2. Operating Voltage: 24 VDC
3. Operating Current: Standby Current: 0.06mA; Alarm Current: 30mA
4. Operating Environment: Temperature: -10~ +50’C; Relative Humidity: 95%
5. Field Programmable Sensitivity: 0.102dB/m-0.316dB/m-3 levels
6. Dimensions: Diameter 100mm, Height 44.5mm
