Specifications :
| Model |
NFC6 |
NFC9 |
NFC10 |
| Extinguisher Capacity |
6Litres |
9Litres |
10Litres |
| Fire Rating |
8A 113B |
13A 183B |
13A 183B |
| Working Pressure |
14 to 15 Bar |
| Test Pressure |
30 Bar |
| Total Weight |
13Kg |
17Kg |
18Kg |
| Range of Discharge |
6-8m |
8-9m |
9-10m |
| Duration of Discharge (Minimum) |
16Sec |
22Sec |
28Sec |
| Operating Temperature |
+5°C to + 60°C |
Features :
- Rugged, durable, reliable fire protection.
- Incorporated with high pressure external CO2 cartridge.
- Easy maintenance.
- Field rechargeable.
- Simple and safe operation.
- Safety valve is provided on the cartridge and the main valve to ensure maximum safety.
- Electrostatic powder painting after shot blasting ensures maximum corrosion resistance.
- Internally coated with Polyolefin & thermosetting polymer powder using whirl sintering process.
Applications :
Cartridge type extinguishers are designed for the protection of ordinary
and high risk hazards. It can be used for reliable fire protection in
many industries and applications including refining, petrochemical, oil
and natural gas production, mining, transportation, utilities, metal
processing, painting process areas, welding areas, material storage
areas and many others.
|
