Specifications :
| Model |
NFIC6 |
NFIC9 |
NFIC10 |
| Extinguisher Capacity |
6Litres |
9Litres |
10Litres |
| Fire Rating |
8A 113B |
13A 183B |
13A 183B |
| Working Pressure |
14 to 15 Bar |
| Test Pressure |
30 Bar |
| Total Weight |
12Kg |
16.5Kg |
17.5Kg |
| Range of Discharge |
6-5m |
8-9m |
9-10m |
| Duration of Discharge (Minimum) |
16Sec |
22Sec |
28Sec |
| Operating Temperature |
+ 5°C to + 60°C |
Features :
- Rugged, durable, reliable fire protection.
- Incorporated with high pressure internal CO2 cartridge.
- Easy maintenance.
- Field rechargeable.
- Simple and safe operation.
- Safety valve is provided on the main valve to ensure maximum safety.
- Electrostatic powder painting after shot blasting ensures maximum corrosion resistance.
- Internally coated with Polyolefin & thermosetting polymer powder using resin using whirl sintering process.
- Ideal for use in corrosive and harsh service conditions such as offshore platforms and marine jetties.
Options :
• Special Extinguishers which are freeze protected up to -20° C
• Plastic base
|
