| Automatic Dry Powder Units |
SPECIFICATIONS
| Model |
ND4.5 MATIC |
ND6 MATIC |
ND10 MATIC |
ND12 MATIC |
ND15 MATIC |
ND20 MATIC |
ND25 MATIC |
ND30 MATIC |
| Extinguisher capacity |
4.5kg |
6kg |
10kg |
12kg |
15kg |
20kg |
25kg |
30kg |
| Working pressure |
15bar |
| Test pressure |
30bar |
| Total weight |
8.5kg |
10.5kg |
15.5kg |
17.6kg |
25kg |
33.5kg |
39kg |
45kg |
| Distance between unit & risk |
1.5 - 4m |
| Duration of discharge |
10-12 sec |
14-16 sec |
16-18 sec |
18-22 sec |
22-26 sec |
26-31 sec |
30-35 sec |
35-40 sec |
| Protected area of coverage |
10m2 (effective when mounted at 3meter height) |
| Operating temperature |
68°c, optional: 79°c / 93°c |
Features :
- Ready for immediate risk protection, no need for piping.
- Fully automatic release to extinguish class a, b, c & electrical fires effectively.
- Different sizes are available to protect various sizes of hazard areas.
- Rigid construction to provide maximum protection for the risk areas.
- Easy assembly and easy maintenance.
- Electrostatic powder painting after shot blasting ensures maximum corrosion resistance.
Applications :
Well suited for oil furnaces, paint spray booths, flammable liquid storage areas, electrical
Hazard areas etc. |
|
|
|
