Features

• Advanced digital sensing technique
• Intelligent Drift compensation
• Built in 8 bit microprocessor
• Self Diagnosis and history log
• Electronically addressable
• Sensing chamber for exceptional dust proof ability and LED for 360° vision
• Algorithm maps for faster response and false alarm rejection
• Secure and speedy communication
• Built in remote indicator output
• Duplicated address report
• Unique low profile design
• EN54 compliance

Technical Specifications

1. Operating Voltage: 24 VDC Loop
2. Standard: EN54-part 7
3. Operating Current: Standby Current 0.6mA ; Alarm Current 3mA
4. Operating Environment: Temperature: -10~+50°C ; Relative Humidity: 95%
5. Field Programmable Sensitivity: 0.102dB/m~0.316dB/m-3 levels
6. Dimensions: Diameter 100mm, Height 44.5mm
