Features

• Loop powered sounder
• Compatible with digital range of detectors
• Multi mode can be configured as single address for evacuation, dual address for alert / evacuation of virtual address to operate with one detector plus programmable evacuation
• Cable-free application
• Low power consumption
• Wall mounted (stand alone with cover) or ceiling mounting Electronically addressable

Technical Specifications

1. Operating Voltage: 24 VDC Loop
2. Operating Current: Standby Current 1mA ; Alarm Current 5mA
3. Sound output: 85dB @ 1 metre
4. Dimensions: Diameter 148mm, Height 34.4mm (without cover) ; Diameter 148mm, Height 49mm (with cover)
