Features

• Drift compensation suit environment changing extensively
• Integrated algorithm for analyzing fire, improving the sensitivity highly
• Self-diagnostic
• Removable innovative sensing chamber, easy for maintenance
• Reporting dirt fault for contaminated chamber

Technical Specification

Operating Voltage:  24VDC(16VDC -28VDC)
Standby Current :  60MA
Alarm Current: 10mA~30mA
Action Temperature: 58°C
Wiring : Polarized two-wire for power
Ingress Protection Rating : IP22
Environment Temperature: -10~+50°C
Relative Humidity: 95%, non condensing
Dimension: Diameter 100mm; Height 56mm (with base)
